30L 200kHz Digital Ultrasonic Cleaner for Semiconductor Wafers | High Frequency Ultrasonic Bath, China OEM Lab Equipment Supplier

1. Designed for advanced wafer, microchip & photonic device cleaning workflows

2. 30L SUS304 ultrasonic bath with timer, heater, digital degas & sweep

3. OEM ultrasonic solution from China with higt quality and lifetime support

SKU: YLS3230-200

$1,402.05piece

17 People watching this product now!

No minimum order required. Enjoy discounts on larger quantities


Quantity ( piece ) 1 – 10 11 – 50 51 – 100 >100
Produce (days) 2 5 10 Negotiable
  • Warranty 1 year
  • 30-Day returns

Payment Methods:

Description

Top of the series, the YLS3230-200 is purpose-built for wafer cassette, mask frame, or multiple-sample chamber cleaning in semiconductor labs. Its 30L capacity supports bulk handling while maintaining precise 200kHz cavitation intensity—safe even for ultra-thin substrates and nanofabricated surfaces. Key features include programmable degas cleaning/pulse cleaning/sweep control, full-range digital heating (20–80°C), and durable SUS304 construction. An excellent fit for QA/QC labs, pilot-scale fabrication, or process development clean zones.

Product Features:

  • 32 x 200kHz 25 Watts Transducers – 800 Watts Efficient
  • Generous 30L Tank Capacity & Dimensions 50x30x20cm
  • 1 – 9999s Digital Time Setting
  • Heating Function Room Temperature – 80℃ Range
  • Secure Wire Cleaning Mesh Basket
  • Yunyisonic ultrasonic cleaner meets CE + RoHS + FCC (“Limit the use of certain hazardous substances”) standards and comes with a 1-yearFree Parts” warranty
Ultrsaonic Bath Lab 200kHz for Semiconductor Wafers, Silicon Wafers Microchips cleaning

Specification:

Model YLS3230-200 Transducer No. 32 pcs
Frequency 200kHz Ultrasonic Power 0-800W
Capacity 30L Heating Power 1000W
Timer 1~9999s Adjustable Tank Material SUS304
Heater 20°C – 80°C Housing Material SUS304
Tank Size(mm) 500x300x200 Unit Size(mm) 530x330x385
Drain Valve Yes Refurbished No
Function Noise Reduction, Sweep Frequency, Pulse, Degas, Adjustable Power, Digital Control, Heating, Operating Panel Optional Language
Logo/Pattern Silk screen printing, Laser Printing, UV printing, PVC, Other

Box Contents:

1 x Professional Ultrasonic Cleaner
1 x Durable Mesh Cleaning Basket
One cover, one power cord, one manual warranty card certificate of conformity.

Packing type:

One unit filled with thick foam, then standard export corrugated carton or wooden box.

More Unit

Ultrasonic cleaning bath with beakers in laboratory setting

200kHz Series

Heater 20–80°C · Timer 1–9999s · SUS304 Unit

Model Transducers Cap Frequency UT Power Heat Pwr Size(LxWxH mm)
(PCS) (L) (kHz) (W) (W) Tank Unit
YLS0603-200 6 3.2 200 0-150 300 240x135x100 265x165x280
YLS0605-200 6 4.8 200 0-150 300 240x135x150 265x165x330
YLS0804-200 8 4.5 200 0-200 450 300x150x100 325x175x280
YLS0806-200 8 6.5 200 0-200 450 300x150x150 325x175x330
YLS1610-200 16 10 200 0-400 600 300x240x150 325x265x330
YLS1614-200 16 14 200 0-400 600 300x240x200 325x265x380
YLS2015-200 20 15 200 0-500 1000 330x300x150 355x325x330
YLS2019-200 20 19 200 0-500 1000 330x300x200 355x325x380
YLS3222-200 32 22 200 0-800 1000 500x300x150 530x330x335
YLS3230-200 32 30 200 0-800 1000 500x300x200 530x330x385

30L Series

Heater 20–80°C · Timer 1–9999s · SUS304 Unit

Model Transducers Cap Frequency UT Power Heat Pwr Size(LxWxH mm)
(PCS) (L) (kHz) (W) (W) Tank Unit
YNLH1430-17 14 30 17 0–1120 1000 500x300x200 600x360x430
YNLH1430-20 14 30 20 0-1400 1000 500x300x200 600x360x430
YNL1630-25 16 30 25 0-800 1000 500x300x200 600x360x430
YL1430-28 14 30 28 0-700 1000 500x300x200 530x330x395
YL1430-33 14 30 33 0-700 1000 500x300x200 530x330x395
YL1030-40 10 30 40 0-500 1000 500x300x200 530x330x385
YL1630-40 16 30 40 0-800 1000 500x300x200 530x330x385
YLS3230-50 32 30 50 0–960 1000 500×300×200 530×330×385
YLS3230-53 32 30 53 0–1120 1000 500×300×200 530×330×385
YL1630-68 16 30 68 0-800 1000 500x300x200 530x330x395
YL1630-80 16 30 80 0-800 1000 500x300x200 530x330x385
YL1630-120 16 30 120 0-800 1000 500x300x200 530x330x385
YL1630-130 16 30 130 0–960 1000 500×300×200 530×330×385
YLS3230-200 32 30 200 0-800 1000 500x300x200 530x330x385
YL1430-2840 14 30 28/40 0-700 1000 500x300x200 530x330x395
YL1630-4068 16 30 40/68 0-800 1000 500x300x200 530x330x395
YL1630-4080 16 30 40/80 0-800 1000 500x300x200 530x330x385
YL1630-40120 16 30 40/120 0-800 1000 500x300x200 530x330x385
YL1630-80120 16 30 80/120 0-800 1000 500x300x200 530x330x385
YNLH1030-20/40/60 10 30 20/40/60 0-1200 1000 500x300x200 600x360x430
YL1630-4080100 16 30 40/80/100 0-800 1000 500x300x200 530x330x385
YL1630-4080120 16 30 40/80/120 0-800 1000 500x300x200 530x330x385
YL1630-255080120 16 30 25/50/80/120 0-800 1000 500x300x200 530x330x385
YL1630-4080100160 16 30 40/80/100/160 0-800 1000 500x300x200 530x330x385
YL1630-4080120170 16 30 40/80/120/170 0-800 1000 500x300x200 530x330x385
200kHz Ultrasonic Cleaner for Labs, Universities and advanced microelectronics
YL Multi Frequency Lab Ultrasonic Cleaner Performance Config

Why Choose Yunyisonic 200kHz  Series Ultrasonic Cleaner?

Designed specifically for the highest standards in semiconductor and lab research—200kHz is industry-proven as the only safe frequency for wafer and chip cleaning.

Factory-direct supply with full OEM/ODM and after-sales support.

Trusted by labs, universities, and microelectronics R&D centers worldwide.

Features & Applications
200kHz High-Frequency Cleaning – Ideal for submicron contaminant removal from silicon wafers, microchips, MEMS, and photonic substrates
Large 30L Capacity – Suitable for wafer carriers, optics trays, and precision glassware
Digital Timer & Heater Control – Supports adjustable cleaning cycles and precise temperature regulation
Degas, Sweep & Pulse Modes – Stable cavitation for uniform cleaning of delicate surfaces and micro-structures
Built with SUS304 Stainless Steel – Thickened tank design for durability and chemical resistance
Noise-Reduced Operation – Optimized for research labs, universities, and semiconductor production environments
OEM & Customization Ready – Branding, tank configuration, and control panel language options available

Yunyisonic ultrasonic cleaner lab R&D use cases

Specification

Product Specifications

Brand

Yunyisonic

Origin

Shenzhen City, China

Capacity

Frequency

Power

Timer

1-9999s

Heater

RT~80°C

Tank Material

SUS304 Stainless Steel

Housing Material

SUS304 Stainless Steel

Voltage

AC 110V 60Hz;AC 220V 50Hz

Plug Type

EU Plug

,

US Plug

,

AU Plug

,

Other Plugs

,

UK Plug

Certificates

CE

,

FCC

,

ROHS

Warranty

1 Year

Customization

485 Port

,

Frequency

,

PLC System

,

Tanks Numbers

Assisted Systems Yunyisonic Laboratory Multi-Function Ultrasonic Cleaning System for Assisted Extraction Emulsification Homogening Dispersion Separation Mixing Defoaming Dissolution Washing

,

,

,

,

,

Function

,

,

,

,

,

,

,

,

Manufacturer

Yunyisonic Shenzhen Co., Ltd.

Packaging

Volumetric Weight 23.1 kg
Package Dimensions 63.5 × 40.5 × 45 cm
