264L Industrial Ultrasonic Cleaner 28/40kHz Frequency | Deep Cleaning for Lab Instruments, Metal Parts & Mold Maintenance

YM Series:

Power Supply:

45L, 61L, 88L, 108L machine using 220V Single phase

135L, 192L, 264L, 360L, 540L, 960L machine using 380V Three phase

Built for Industrial-Grade Cleaning: Large Capacity Meets Intelligent Power

At the heart of the YM60264 is its 264-liter SUS304 stainless steel tank, designed for cleaning medium to large components including engine blocks, molds, mechanical parts, and laboratory tools. Its single or dual frequency (28, 40, 28/40kHz optional) gives users the flexibility to switch between heavy-duty degreasing and delicate cleaning, depending on the application. The 3000W ultrasonic power, paired with a 7500W heating system, ensures efficient particle removal and deep penetration—even for hard-to-reach internal surfaces.

Thanks to the external digital generator, the machine supports adjustable power output (0-100%), adjustable cleaning time (1-99 minutes or continuous mode for over 12hours), and digital temperature control, giving users complete operational control. This system is especially useful for labs, aerospace manufacturers, or tool refurbishing centers where varying material types require tailored settings.

Adjustable Power for Versatile Cleaning

One of the standout features of the 192L Ultrasonic Cleaner is its adjustable power settings. With the ability to control ultrasonic power, users can tailor the cleaning intensity based on the type of contaminants and the sensitivity of the parts being cleaned. For instance, delicate components may require a gentler cleaning cycle, while industrial parts such as engines, molds, or tools may need higher intensity for effective degreasing and rust removal.

This adjustable power ensures that the cleaner is versatile enough to handle a wide variety of tasks, making it the ideal choice for industries that require both precision and power in their cleaning processes.

Versatile Applications Across Multiple Industries

This industrial ultrasonic cleaner is not limited to one sector. Its capabilities span multiple professional fields:

– Scientific & Analytical Labs: Used to clean labware, glass tubes, test containers, and analytical instrument components, ensuring contamination-free surfaces.
– Precision Metalworking: Ideal for degreasing small gears, valves, or finished metal parts without abrasive wear.
– Mold Maintenance & Injection Molding Facilities: Removes wax, oil, and plastic residues from complex mold cavities and channels, extending mold lifespan.
– Aerospace & Automotive Manufacturing: Ensures the removal of carbon buildup, rust, and machining residues from engine components, turbo parts, and gearboxes.
– Electronics Industry: Cleans delicate circuit boards, soldered components, and sensors without causing damage.

With its frequency optional 28khz or 40khz, the YM60264 handles both delicate tasks and rugged industrial cleaning challenges.

Built to Last: Robust Construction and High-Quality Components

The YM60264’s cleaning tank is made of 2.0mm thick SUS304 stainless steel, known for its corrosion resistance and long service life. The outer shell is also constructed from durable 1.0mm SUS201 stainless steel, ensuring protection against mechanical wear and harsh cleaning environments.

Some notable build features include:

– Heavy-duty caster wheels with lock-stopping design for easy machine movement and secure positioning.
– Industrial-grade thick power cord for safe, high-wattage operation.
– 3-pin anti-static grounding plug for enhanced safety.
– Industrial piezoelectric transducers, capable of continuous 24/7 operation with stable ultrasonic output.
– Independent R&D drive board, supporting reliable high-frequency signal conversion.

Every component is selected to support long-term use and high-performance cleaning cycles, even in demanding industrial environments.
